XTY-600W11075-30 the horizontal full automatic medium sized baler is widely applied in printing factory, corrugation industry etc.,professional in dealing with all kinds of waste paper, carton, cardboard. It can have horizontal tying or vertical tying which can be chosen according the requirement.

Pressing: 60tons
Main Motor Power: 22kw
Cooling System: air cooler / water cooler
Cycle Time (unload): 24s
Oil Reservoir: 1000L
Number of Belting: 4lines
Wire Size: Ø2.4-3.2
Feed Opening Size (L*W): 1600*1050mm
Chamber Size (L*W*H): 2100*1100*750mm
Bale Size (L*W*H, L can be adjustable): L*1100*750mm
Bale Density（OCC）: 400-500kgs/m3
Throughput (30-60kgs/m3): 3-7tons/h
Machine Weight: 13tons
Machine Overall Dimension: 7950*3900*3500mm
Tying: Horizontal Tying or Vertical Tying
Feeding Device: Conveyor
Feeding Width: 1600mm
Speed: 12m/min
Power: 4/5.5kw
Weight: 5tons
Overall Dimension: 9000*2100*4500mm

As a baler machine factory, we will do our best to meet all the needs of customers.
