A45 CNC spark erosion machine has three-axis simultaneous control and 5th generation electrical discharging control system, best surface finish Ra≤0.08μm, Min. electrode wear ≤0.05%, standard equipped with 50A controller and Max machining efficiency ≥500mm3/min. Excellent performance and suitable dimension make A45 ideal for making various molds with the strict requirements of surface finish and accuracy.

Main Dimensions of A45 CNC Die Sinking EDM Machine
X×Y×Z travel: 452×300×272mm;
Working table dimension: 600×400mm;
Working tank on the table: 1090×630×445mm

A45 CNC Die Sinking EDM Machine Specifications
No. Name A45
1 Working table dimension(L×W) 600×400mm
2 X, Y, Z axis travel 452×300×272mm
3 Working tank dimension(L×W×H） 1090×630×445mm
4 Highest level of working liquid 290mm
5 End of the spindle to the working table 600mm
6 Capacity of the oil tank 600L
7 Max weight of the electrode 25kg
8 Max weight of the workpiece 400kg
9 Positioning accuracy 6µm
10 Repeat positioning accuracy 3.5µm
11 Weight of machine 3100kg
12 Dimension of machine 1500×1680×2350mm
13 General input 9kVA(50A)
14 Input power 3 Phase 220/60Hz
15 CNC power generator A3-50
16 Max working current 50A
17 Best surface finish Ra≤0.08µm
18 Min. wear of the electrode ≤0.05%
19 Max machining efficiency ≥500mm3/min
20 Interpolation methods Straight line, arc, helix
21 Accuracy compensation options Step pitch compensation of each axis,
gap compensation
22 Min. drive unit 1µm
23 The outer dimension of the controller 1250×550×1800mm
24 Display 15-inch touch screen
25 Remote control different gradesMFR0-3
